S-8192S 92+92Wh Dividable V-mount Battery Pack

›  Divide into 2 parts of 92Wh capacity each (Patent)

›  Not restricted by IATA air transportation regulations

›  Li-ion, 14.4V, 92+92Wh capacity

›  D-tap output socket

›  4-level LED power indicator

›  V-mount connection

›  Multiple circuit protections


Features

Large Capacity Battery, IATA Comply

Patented dividable battery design

The IATA DGR regulations restricted the air transportation of over 100Wh Li-ion battery packs. SWIT provides the solution of Dividable Battery to comply with IATA regulations. S-8192S can be divided into 2 parts, and each part contains 92Wh capacity, not restricted by air transportation. And when using S-8192S, just assemble the 2 parts, you can get a Li-ion battery pack of 184Wh large capacity.

184Wh / 12.8Ah High Capacity

When assembled, the S-8192S consists of 20pcs 18650 battery cells, and reaches 184Wh / 12.8Ah high capacity. S-8192S can run approx 6 hours for normal 30W ENG cameras, and has no problem to fly with.

Reliable V-mount Connection

S-8192S is the standard V-mount connection and we adopt the high quality fiber glass V-wedge that ensures the reliable mounting.

Build-in D-tap DC Output Socket

A D-tap DC output socket is equipped on the top side of S-8192S battery, for DC14.4V (Nominate) connection, such as on-camera lights, monitors, wireless transmitter, etc. The Max Power from D-tap is 100W, 8A.

4-level LED Power Indicator

On the side of the battery, there’re 4-level LED power indicators to check the battery remaining capacity. You can get a quick view of capacity before using.

无标题文档

Nominal Voltage

14.4V

Capacity

92+92Wh/6.4+6.4Ah

Max output power

In total:100W

Electrodes:100W,8A
D-tap:100W,8A

Mount Type

V-mount

Charging Temperature

0-40°C
      Discharging Temperature-20°C-50°C(Capacity and Max Load may decrease when operating below 0°

Net weight

Net 1.27kg; With package 1.4kg

Dimensions

168×101×60mm
Basic Package

MSRP

MSRP

MSRP

  • S-8192S

    92+92Wh Dividable V-mount Battery Pack

    Can be divided into 2 parts of under 100Wh capacity, not restricted by IATA air transportation; D-tap output, LED power indicators

  • S-8152S

    73+73Wh Dividable V-mount Battery Pack

    Can be divided into 2 parts of under 100Wh capacity, not restricted by IATA air transportation; D-tap output, LED power indicators

  • S-8192A

    92+92Wh Dividable Gold Mount Battery Pack

    Can be divided into 2 parts of under 100Wh capacity, not restricted by IATA air transportation; D-tap output, LED power indicators

  • S-8152A

    73+73Wh Dividable Gold Mount Battery Pack

    Can be divided into 2 parts of under 100Wh capacity, not restricted by IATA air transportation; D-tap output, LED power indicators

  • PC-P430S

    4-ch V-mount Fast Charger

    3A×4 fast charging current; AC-DC adapter output, LED charging indicators

  • S-3822S

    2-ch V-mount Fast Charger

    2-ch simultaneous charging, 3A fast charging, Portable, support AC-DC adaptor output

  • S-3812S

    2-ch V-mount Super Fast Charger

    2-ch simultaneous charging, Max 6A fast charging, support AC-DC and Battery-DC adaptor output, LCD display working status

  • S-7104

    D-tap to Pole-tap DC Cable

    Pluged into D-tap socket and output DC via 5.5mm pole-tap
